Single Sheet Variable Data UV Inkjet Printing and Inspection-Arojet

Basic Info.

Model NO.

Supplies

UV Ink

Packaging

Bubble

Print Head Type

on-Demand Piezoelectric Print Head(Konica)

Print Head Life

100 Billion Actuations Per Print Head

Print Head Width

36 mm

Ink Color

Single Color

Curing Type

UV-LED Curing

Printing Speed

0-45 M/Min

Weight

218 Kg

Printing Software

Magicdata Variable Data-Editing Software

Ink Control

Negative Pressure for Ink Control

Ink Type

High-Quality Eco-Friendly UV Ink

Lengthways Printing Precision

600 Dpi

Crosswise Printing Precision

200 Dpi-1200 Dpi Adjustable

Material Feeding Way

Single Sheet/Roll to Roll

Power Supply

AC 100V-240V, 50Hz-60Hz, 2.7kw

Trademark

Arojet

Transport Package

Wooden Case

Specification

139*83*150 cm

Origin

China

HS Code

8443321300

1. production overview

C1 sheet-fed digital variable data inkjet printing machine is suitable for different materials with different shapes. For example, it can print variable data barcode, two-dimension code, serial No., date code, etc. on bottle cap, glass cup, ceramics, metal and so on. The printing speed is 0-45m/min with physical resolution up to 360dpi.

The resolution can reach 200dpi at the speed of 50m/min. The inkjet printing grade can reach A level and the scanning qualified rate up to 99.9%. The minimum character to be printed is 1mm. The minimum size of two-dimension code printed is 5*5mm.

Sheet-fed featured C1 model can be used for roll to roll printing too when the printing speed is not required too high. It is widely applied to the industries of food, beverage, drug, electronics, hardware, etc., provides enterprises with reliable-quality and suitable-price inkjet printing solutions.

Single Sheet Variable Data UV Inkjet Printing and Inspection

2.Product Features

Single sheet or roll to roll feeding platform

Industrial piezoelectric printhead with high precision.

UV-LED curing with high quality.

Eco-friendly water cooling system.

Wide range of printed media material.

Large applications of inkjet coding and marking.

Single Sheet Variable Data UV Inkjet Printing and Inspection

3.Product Specifications

Model:	C1	Printing software:	MagicData variable data-editing software
Print head type:	Industrial piezoelectric print head (KONICA)	SDK:	Provide interface to support second development
Print head life:	100 billion actuations per print head	Ink control:	Negative pressure for ink control, positive pressure for nozzle cleaning
Print head material:	Stainless steel, Nickel alloys & Epoxy adhesive	Ink type:	High-quality Eco-friendly UV ink
Print head width:	36mm (single print head)	Ink color	Single color
Nozzle quantity:	512 pcs (single print head)	Curing type:	UV-LED curing
Nozzle rows:	2 rows	Printing speed:	0-45m/min. (Affected by material, resolution, environment, platform etc. factors)
Printing modules:	8 groups	Lengthways printing precision:	360dpi
Max. width of printing:	288mm	Crosswise printing precision:	200dpi-1200dpi adjustable
Distance from print head to material:	0.5mm-2mm	Weight:	270KG
Material feeding way:	Single piece, roll to roll	Size:	1.39m0.83m1.50m (print head case+curing case)
Power supply:	AC 100V-240V, 50Hz-60Hz	Working temperature:	5°C-40°C
Interface type:	USB 2.0	Environment humidity:	20%-65% RH

4.Print Head

C1 model adopts KONICA all-steel piezoelectric printhead, with compact design and high precision. It can offer a range of solutions to various customer applications.

Shear mode, piezoelectric DOD printhead

512 nozzles, 360dpi high resolution

Compatible with UV ink with good printing effect

Easy to operation with negative pressure ink control

5.Printing Software

C1 model uses AROJET self-designed MagicData software, which is specially developed for monochrome and multi-color variable data printing (VDP), supporting many types of object to be printed, such as texts, dates, times, graphics, logos, serial numbers, QR codes, barcodes, MICR fonts and photo images.

MagicData software has a friendly interface, easy to understand and easy to operate. Its workflow of editing, modifying, typesetting, integrating, splitting as well as input and output is brief and streamlined. It provides versatile choices to your inkjet printing solution.

Single Sheet Variable Data UV Inkjet Printing and Inspection

6.Printing Ink

UV ink is a kind of economical, efficient and green eco-friendly ink, which has covered all printing industries. C1 model adopts professional UU-8008-1 type UV ink for inkjet printing. It features fast drying, vivid image and good printing quality as well as below unique characteristics.

Inkjet printability
Anti-scratch, friction resistance and anti-corrosive
Hazardous substance content conforms to RoHS standard.

Single Sheet Variable Data UV Inkjet Printing and Inspection

7.Reference Video

https://arojet.en.made-in-china.com
https://arojet.en.made-in-china.com

This product will finally contribute to bringing profits for manufacturers. It helps cut expenditures both in labor and energy consumption. It is guaranteed with a superb crosswise and lengthways printing precision. For manufacturers, the product brings about enormous economic benefits, because it helps improve productivity and cut expenditure on labor. It is guaranteed with a superb crosswise and lengthways printing precision.
